How Sintering Furnace Temperature Uniformity Affects PTFE Cloth

Jiangsu Aokai New Materials, a leading manufacturer and original factory of PTFE high-temperature cloth, takes you to understand: To guarantee the sintering quality of PTFE high-temperature cloth, it is essential to implement full-process management covering equipment, technology, testing and control, so as to keep the PTFE high-temperature cloth in an ideal temperature field at all times.

1. Equipment: Lay a Foundation for Uniform Heating of PTFE High-temperature Cloth

Heating Method: In the sintering furnace for PTFE high-temperature cloth, resistance heating with multiple sets of heating elements distributed at multiple points delivers more uniform heating; alternatively, induction heating enables the cloth to generate heat internally, realizing volumetric and even heating.

Furnace Chamber Structure: To improve the temperature field uniformity of PTFE high-temperature cloth, a circular furnace chamber design reduces edge effects, placing the cloth in a symmetric and balanced temperature field.

Airflow & Loading Layout: For sintering, forced draft fans circulate internal airflow. Meanwhile, the loading arrangement of PTFE high-temperature cloth must be rationally planned to avoid overcrowding or shielding, ensuring even heat absorption for every piece of cloth.

2. Technology: Precisely Control the Sintering Condition of PTFE High-temperature Cloth

Sintering Temperature: The sintering temperature of PTFE high-temperature cloth must be precisely controlled within the range of 360~380℃, to ensure complete melting of the PTFE coating while maintaining a crystallinity of 50%-60%.

Heating Curve: Segmented stepwise heating effectively prevents cracks on PTFE high-temperature cloth caused by thermal shock.

Holding Time: Sufficient heat preservation allows heat to fully penetrate the core of the cloth. The specific duration is set according to the thickness of PTFE high-temperature cloth and equipment characteristics.

Cooling Control: Finished PTFE high-temperature cloth requires slow and controlled cooling to avoid internal stress or uneven shrinkage caused by rapid temperature drop.

3. Testing: Accurately Monitor the Temperature of the PTFE Sintering Furnace

Sensors: High-precision thermocouples or thermal resistors are adopted to monitor the furnace temperature.

Multi-point Temperature Measurement: At least 5 thermocouples are evenly arranged in the working area for regular thermal field mapping and calibration of the sintering furnace.

Uniformity Inspection: The furnace temperature uniformity is tested regularly in accordance with industry standards, with the temperature difference in the working area for PTFE high-temperature cloth stably controlled within ±5℃.

4. Control: Achieve Dynamic and Balanced Temperature Field for Sintering

Zoned Independent Temperature Control: The sintering furnace is divided into multiple zones with independent temperature adjustment, ensuring balanced and free heating for all parts of the PTFE high-temperature cloth.

Advanced PID Algorithm: High-response PID control systems accurately correct temperature deviations and fluctuations during the sintering process.

Computer Simulation: CFD simulation technology is introduced to optimize the flow field and temperature field design inside the furnace, fundamentally reducing batch temperature differences of finished products.

Furnace temperature uniformity directly determines the wear resistance, heat resistance grade and surface cleanliness of PTFE high-temperature cloth. Precise temperature control in every detail is the key dividing line between ordinary-grade and high-performance premium PTFE high-temperature cloth.

The above content is provided by Jiangsu Aokai New Materials Technology Co., Ltd.
