Why Does PTFE High-Temperature Cloth Wear Slowly Under Heavy Friction Conditions?

As a professional manufacturer of PTFE high-temperature cloth, Jiangsu Aokai New Materials will explain why PTFE-coated glass fiber cloth exhibits reduced wear under heavy friction conditions. Its wear resistance mechanism is not caused by a single factor, but can be understood from the following aspects:

1. Extremely Low Friction Coefficient and Self-Lubricating Property

Polytetrafluoroethylene (PTFE) has one of the lowest friction coefficients among solid materials (dynamic friction coefficient approx. 0.04–0.10).

· Molecular Structure: The carbon chain of PTFE is tightly wrapped by fluorine atoms with high and uniform electron cloud density, resulting in extremely weak intermolecular forces, forming a “molecular lubricating layer”.

· Interfacial Slip: During friction, PTFE molecular chains easily align along the friction direction and shear on the counterface (e.g., metal or other hard surfaces). Friction mainly occurs inside the material or transfer film rather than direct adhesion and plowing at the interface, greatly reducing friction resistance and shear stress and slowing down the wear rate.

2. Load-Bearing and Restraining Effect of the Glass Fiber Fabric Core

PTFE high-temperature cloth is a composite material with glass fiber fabric as the substrate and PTFE as the coating.

· Main Load Carrier: Glass fiber fabric provides high tensile strength and dimensional stability. Under heavy friction, glass fiber bears most of the normal load and shear force, preventing the PTFE coating from macroscopic tearing or plastic flow caused by excessive stress.

· Restriction of Wear Debris Formation: The fiber framework limits the size of PTFE “strip wear debris”. Pure PTFE tends to form large debris due to extensive molecular chain stretching, while the glass fiber network divides PTFE into micro-regions, confining wear to small areas with fine particles. Wear appears as “micro-abrasion” rather than “macroscopic delamination”, significantly lowering the wear rate.

3. High Heat Resistance and Thermal Stability

Heavy friction is inevitably accompanied by frictional heat generation. The advantages of PTFE high-temperature cloth are:

· Wide-Temperature Stability: PTFE maintains stable performance from −200°C to 260°C. Its friction coefficient decreases slightly with rising temperature (within a certain range), avoiding softening, adhesion or thermal decomposition caused by local high temperatures.

· Heat Dissipation of Glass Fiber: Glass fiber has good thermal conductivity, helping to dissipate frictional heat, reduce local hot spots, and prevent premature failure of PTFE due to heat accumulation.

4. Chemical Inertia and Anti-Adhesion Property

PTFE is resistant to almost all chemical corrosion. In heavy friction environments with lubricants, dust or corrosive substances, its surface is less prone to chemical wear (e.g., oxidation or corrosion-accelerated wear). Its low surface energy makes it difficult for counter materials to cold-weld or adhere to the substrate, thus preventing adhesive wear.
