Red PTFE Tape

Red PTFE Tape is also called PTFE Adhesive Tape.

1.This surface has good non adhesion and sliding property;
2.Good electrical insulation;
3.Can be used in a wide range of temperatures;
4.Good breakdown voltage resistance;
5.Certificates: ISO 9001:2015, FDA;
6.Excellent service & support including pre-sales, in-sales & after-sales;
7.Accept customize;
8.OEM/OBM service.


Availability:



Inquire

Red PTFE tape PTFE Adhesive Tape

Product Category

Product Description

Red PTFE tape is specifically designed for high-performance applications that require a strong, reliable bond, often in environments where durability and resilience are essential.

Product Features of Red PTFE tape

The red color differentiates it from standard white or other PTFE tapes, the bright red color helps with visibility during application, making it easier to handle and position.

Applications of Red PTFE tape

● Can be laminated with metals, plastics and ceramics as general sliding materials.

● For endless belts of polyethylene laminators

● For roll wrapping of polyethylene laminators

● For insulation of coils as a class H insulating material.

Technical Parameters of Red PTFE tape

Product code

Total thickness mm

Standard width mm(in)

Maximum width mm(in)

Length m

M-R

0.1

10,13,19,25,30,38,50

500

10-33

Red PTFE Tape Manufacturer

Aokai PTFE focuses on providing high-quality PTFE coated fiberglass fabric and excellent service levels. We are a professional PTFE coated fiberglass fabric manufacturers that will help you in the following areas: basic materials, finished product quality, delivery, and after-sales service. Aokai provides you with wholesale, customization, design, packaging, industry solutions, and other OEM OBM services. Our professional R&D team, production team, quality inspection team, technical service team, and pre-sales & after-sales service team will provide you with a one-stop service, save your time and ensure the most professional product quality.

Cooperation Partners

Where to buy Red PTFE tape?

If you have any questions about Red PTFE tape, please don't hesitate to contact us at mandy@akptfe.com. We will provide detailed information and technical support about product features, specifications, solutions and customization options... Welcome you to visit our factory!

For inquiries or to place an order, please contact us.

Q Can I order custom widths or lengths?

A Yes. We offer custom widths, thicknesses, and roll lengths to fit your process. Contact our sales team with your specifications and required quantity.
Q How should I store and handle the tape?

A Store in a cool, dry place away from direct sunlight and heat sources. Avoid prolonged exposure to moisture. Keep the roll in its original packaging when not in use.
Q What is the typical lead time?

A Standard products ship within 7 business days after order confirmation; custom options may take longer. We’ll confirm a firm lead time with you at order.
Q Is the adhesive silicone-based, acrylic, silicone-acetate?

A The adhesive is silicone-based, however, customer can customize acrylic-based tape, which provides higher adhesion.
Q What is the difference between PTFE silicone adhesive tape and PTFE acrylic tape?

A
Temperature performance

● Silicone adhesive:

Excellent high-temperature stability and remains flexible at low temperatures; suitable for thermal cycling and gaskets/seals.

● Acrylic adhesive:

Good overall temperature performance but generally not as flexible as silicone; may become more brittle at very low temperatures or soften at high temperatures.

Chemical resistance and environment

● Silicone adhesive:

Excellent resistance to moisture, water immersion, UV exposure (for outdoor use), and many chemicals; maintains elasticity.

● Acrylic adhesive:

Good chemical and UV resistance for many environments but typically less flexible than silicone; weathering resistance is formulation-dependent.

Flexibility vs rigidity

● Silicone adhesive on PTFE:

More flexible, able to accommodate movement, vibration, and thermal expansion without losing seal.

● Acrylic adhesive on PTFE:

Typically stiffer; strong initial hold but less forgiving with movement; better for rigid, high-tack bonds.
